Project
|
Parameter
|
|
|
Product number
|
S8 (203DPI)
|
|
product type
|
printer
|
|
Listed version
|
BT version
|
|
printing method
|
heat sensitive
|
|
Print head effective printing width (Max)
|
208mm, 1664dot
|
|
Resolution
|
203dpi (8dots/mm)
|
|
Print point size
|
0.125x0.125mm (1mm=8dots)
|
|
Concentration range
|
0,1,2
|
|
Communication method/interface
|
USB, BT 2.0/4.0
|
|
Machine size
|
290*90*60 (L*W*H)
|
|
|
Printing speed (Max)
|
Maximum speed 12mm/S
|
|
|
Paper roll outer diameter (Max)
|
30mm
|
|
Maximum loading width (including backing paper)
|
216mm
|
|
Supported paper roll types
|
continuous paper, fanfold paper
|
|
Supported Roll Forms
|
Roll-out
|
|
Paper tearing method
|
paper tearing knife
|
Human-computer interaction
|
Function button
|
Function key*1,
|
|
Indicator light
|
Blue light*1, red light*1, green light*1
|
|
|
Storage temperature
|
-20～70℃
|
|
Storage humidity
|
5~95% (non-condensing)
|
|
Operating temperature
|
0℃～50℃
|
|
Working humidity
|
10~90% (non-condensing)
|
|
Print head life
|
50KM
|
|
Battery
|
2600mah
|
|
Adapter In/Out
|
Input: AC 100V-240V, 50-60Hz Output: 5V-2A
|
Instruction set programming language
|
Instruction set (programming language)
|
YPL
|
|
|
Sensor
|
Transmission sensor, temperature sensor, cover opening and closing sensor
|
|
Detection
|
Cover opening and closing detection, paper out detection, voltage detection, temperature detection
|
